12" coaxial loudspeaker with 40-18,000Hz response.
250Wrms (AES standard) power handling and 97dB sensitivity.
2.5" high temperature copper voice coil wound on polyimide for increased reliability.
Robust and reliable pressed steel frame ferrite magnet LF driver.
Compact, lightweight neodymium compression driver - 80o nominal coverage.
Nominal diameter 305mm/12in.
Features:
-
Power rating 1250Wrms
-
Nominal impedance 8?
-
Sensitivity 297dB
-
Frequency range 40-4000Hz
-
Voice coil diameter 64mm/2.5in
-
Chassis type Pressed steel
-
Magnet type Ferrite
-
Magnet weight 1.2kg/42oz
-
Coil material Round copper
-
Former material Polyimide
-
Cone material Kevlar loaded paper
-
Surround material Cloth-sealed
-
Suspension Single
-
Xmax 45mm/1.75in
-
Xmax3 2.5mm/0.098in
-
Gap depth 8mm/0.31in
-
Voice coil winding width 13mm/0.51in
