IXL Luminate Dual 3in1 Bathroom Heater/Exhaust Fan w/ Light - White
The Tastic Luminate Dual 3 in 1 Bathroom Heater, Fan and Light is the latest in IXL's premium Bathroom range, ideal for medium-sized bathrooms.
With its 480m3/hr powerful airflow extraction, Tastic Luminate Dual's bathroom exhaust fan removes steam effortlessly, while the two 800W bathroom heat lamps use Halo Heat™ technology to provide long lasting warmth when the chill sets in.
The Tastic Luminate Dual features a sleek and contemporary fascia design and provides superior illumination through a dimmable warm/cool LED light.
Inclusions of a plug and play low voltage wall switch, CAT6 cable, 6 metres of ducting and an exterior outlet vent ensures simple installation.
Powerful Extraction: 480m3/h Airflow
Long Lasting Instant Heat: 2 x 800W Infra-Red Heat Lamps, auto cut off timer
Switchable LED Light: 25W Dimmable LED (Warm/Cool)
IXL has designed Tastic Luminate to be simple and easy to install by utilising the CAT6 cable and plug and play connection, it significantly reduces the installation time.
Tastic Luminate is compliant with NCC in Australia, and G4 Building Codes and Healthy Home Standard for bathrooms and kitchens in New Zealand.
Tastic Luminate Dual Bathroom Ceiling Heater is proudly designed and manufactured in Australia.
- Plug & Play Wall Switch
- Dimmable Warm/Cool LED Light Panel
- 2 x 800W Heat Lamps
- Exhaust Fan with 6m Duct and Exterior Outlet Vent
- Finish/Colours White
- Airflow Extraction (m3/h) 480
- Heat Lamps 1600W
- Ducted Yes
- Minimum Ceiling Height 2.2
- Clearance Required above Unit (mm) 30
- Colour Temperature (Kelvins) 3000/4000
- Current Ratings (Amps) 7
- Cutout Size (mm) 712 x 332
- Exhaust Capacity (l/s) 133
- Exhaust Capacity (m3/h) 480
- Fan Size (mm) 170
- Fascia Dimensions (mm) 737W x 367D
- Half Heat Function Yes
- Instant Heat Yes
- Inline Fan Ducted to Outside Yes (6m of ducting included)
- LED Light Output (Lumens) 1800
- Made in Australia Yes
- Max. Height of Unit (mm) 195
- Max. Ceiling Height (m) 3.3
- Min. Ceiling Height (m) 2.2
- Supply (Volts) 240
- Area Suitability in Room without Shower 60
- Area Suitability in Room with Shower 24
- Total Ceiling Cavity Required (mm) 245
- Watts (Fan in Brackets) 1675 (75)
- Weight of Unit (kg) 10
- Centre LED Voltage (W) 25
- Wall Switch Yes
- Power Cable Length (m) 1.2
- Unit Dimensions (mm) 367W x 737L x 207D
- Dimmable LED Light (Warm White/Cool White/Daylight) Yes
